EN50155 10G Uplinks Managed Ethernet Switches

10G Uplinks + Powerful OS5 / OS4 / OS3 Platform

Built-in ECN standard with optional Layer3 Lite management, R-NAT, TBN models are available. Rugged housing comes with up to 8-port 10G speed uplink make the series so powerful for rail applications.

OS5 VS. OS4 VS. OS3 Platform

	OS5	OS4	OS3
L2+ & ECN IEC 61375-3-4
L3L (Optional)
ETBN61375-2-5 (Optional)
L3 (Optional)
NAT (Optional)
PTP (Optional)
R-NAT (Optional)
Macsec (Optional)

PRODUCT FILTER

All
OS5
OS4
OS3
L3/L3Lite
PoE
Non-PoE
Fiber
Full Giga
Rack-mount
DIN-Rail

OS5
T(P)GS-H7624XT (IP54)
24 GT + 6 10G Copper M12 Push-Pull X-coded (PoE) EN50155 Managed Ethernet Switch
OS5
T(P)GS-H7624XFT (IP54)
24 GT + 4 10G Copper + 2 10G QODC M12 Push-Pull X-coded (PoE) EN50155 Managed Ethernet Switch
OS5
T(P)GS-H7808XT (IP54)
8 2.5G + 8 10G Copper M12 Push-Pull X-coded (PoE) EN50155 Managed Ethernet Switch
OS4
T(P)GS-R6804XT (IP67/IP54)
4 1G/2.5G Copper + 8 10G Copper (w/8 PoE), EN50155 OS4 Managed Ethernet Switch
OS4
T(P)GS-R6616XFT (IP21)
16 10/100/1000T + 4 10G Copper + 2 10G Q-ODC Fiber (w/8/10/12/16 PoE), EN50155 OS4 Managed Ethernet Switch
OS4
T(P)GS-R6616XT (IP21)
16 10/100/1000T + 6 10G Copper (w/8/10/12/16 PoE), EN50155 OS4 Managed Ethernet Switch
OS4
T(P)GS-R6416XFT (IP21)
16 10/100/1000T + 2 10G Copper + 2 10G Q-ODC Fiber (w/8/10/16 PoE), EN50155 OS4 Managed Ethernet Switch
OS4
T(P)GS-R6416XT (IP67/IP54)
16 10/100/1000T + 4 10G Copper (w/8/10/16 PoE), EN50155 OS4 Managed Ethernet Switch
OS4
T(P)GS-R6608XFT (IP67/IP54)
8 10/100/1000T + 4 10G Copper + 2 10G Q-ODC Fiber (w/8/10/12 PoE), EN50155 OS4 Managed Ethernet Switch
OS4
T(P)GS-R6608XT (IP21)
8 10/100/1000T + 6 10G Copper (w/8/10/12 PoE), EN50155 OS4 Managed Ethernet Switch
OS4
T(P)GS-R6408XFT (IP21)
8 10/100/1000T + 2 10G Copper + 2 10G Q-ODC Fiber (w/8/10 PoE), EN50155 OS4 Managed Ethernet Switch
OS4
T(P)GS-R6408XT (IP67/IP54)
8 10/100/1000T + 4 10G Copper (w/8/10/12 PoE), EN50155 OS4 Managed Ethernet Switch
OS3
T(P)GS-L6416XFT (IP67/IP54)
16 10/100/1000T + 2 10G Copper + 2 10G Q-ODC Fiber (w/8/10/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6416XT (IP67/IP54)
16 10/100/1000T + 4 10G Copper (w/8/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6216XT (IP67/IP54)
16 10/100/1000T + 2 10G Copper (w/8/10/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6216XF (IP67/IP54)
16 10/100/1000T + 2 10G Q-ODC Fiber (w/8/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6408XFT (IP67/IP54)
8 10/100/1000T + 2 10G Copper + 2 10G Q-ODC Fiber (w/8/10 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6408XT (IP67/IP54)
8 10/100/1000T + 4 10G Copper (w/8/10 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6208XT (IP67/IP54)
8 10/100/1000T + 2 10G Copper (w/8/10 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6208XF (IP67/IP54)
8 10/100/1000T + 2 10G Q-ODC Fiber (w/8 PoE), EN50155 OS3 Managed Ethernet Switch
OS4
T(P)ES-R6616XFT (IP21)
16 10/100TX + 4 10G Copper + 2 10G Q-ODC Fiber (w/8/10/12/16 PoE), EN50155 OS4 Managed Ethernet Switch
OS4
T(P)ES-R6616XT (IP21)
16 10/100TX + 6 10G Copper (w/8/10/12/16 PoE), EN50155 OS4 Managed Ethernet Switch
OS3
T(P)ES-L6424XFT (IP67/IP54)
24 10/100TX + 2 10G Copper + 2 10G Q-ODC Fiber (w/8/10/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)ES-L6424XT (IP67/IP54)
24 10/100TX + 4 10G Copper (w/8/10/12/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)ES-L6416XFT (IP67/IP54)
16 10/100TX + 2 10G Copper + 2 10G Q-ODC Fiber (w/8/10/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)ES-L6416XT (IP67/IP54)
16 10/100TX + 4 10G Copper (w/8/10/12/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)ES-L6216XT (IP67/IP54)
16 10/100TX + 2 10G Copper (w/8/10 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)ES-L6216XF (IP67/IP54)
16 10/100TX + 2 10G Q-ODC Fiber (w/8/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)ES-L6408XFT (IP67/IP54)
8 10/100TX + 2 10G Copper + 2 10G Q-ODC Fiber (w/8/10 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)ES-L6408XT (IP67/IP54)
8 10/100TX + 4 10G Copper (w/8/10 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)ES-L6208XT (IP67/IP54)
8 10/100TX + 2 10G Copper (w/8/10 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)ES-L6208XF (IP67/IP54)
8 10/100TX + 2 10G Q-ODC Fiber (w/8 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6424XFTR (IP41)
24 10/100/1000T + 2 10G Copper + 2 10G Q-ODC Fiber (w/8/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6424XTR (IP41)
24 10/100/1000T + 4 10G Copper (w/8/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6416XFTR (IP41)
16 10/100/1000T + 2 10G Copper + 2 10G Q-ODC Fiber (w/8/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6416XTR (IP41)
16 10/100/1000T + 4 10G Copper (w/8/16 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6408XFTR (IP41)
8 10/100/1000T + 2 10G Copper + 2 10G Q-ODC Fiber (w/8 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
T(P)GS-L6408XTR (IP41)
8 10/100/1000T + 2 10G Copper + 2 10G Q-ODC Fiber (w/8 PoE), EN50155 OS3 Managed Ethernet Switch
OS3
I(P)GS-6416XSFP
16 10/100/1000T (PoE at/af) + 4 1G/2.5G/10G SFP+ L2+ Industrial Managed Ethernet Switch
